Nestled in the heart of Safat, Kuwait, Nimish Metal has built a reputation for delivering precision and reliability in the metal industry. We take pride in being your trusted source for the Stainless Steel 347 Hex Bar and Rod, a material chosen by engineers for its exceptional performance in demanding environments. Our commitment is to provide not just a product, but a dependable solution that forms the backbone of sturdy and long-lasting projects, backed by our local expertise and dedicated customer service.
The strength of Stainless Steel 347 lies in its specific composition, which is stabilized with columbium to effectively resist intergranular corrosion following exposure to high temperatures. This careful alloying results in impressive mechanical properties, including excellent tensile strength and good creep resistance. It maintains its structural integrity even under sustained stress and heat, making it a wonderfully robust choice for applications where both durability and resistance to corrosive elements are non-negotiable priorities.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 347 | 0.08 max. | 17.0 – 19.0 | 2.00 max. | 9.0-13.0 | 0.045 max. | 0.03 max. | 0.75 max |
| Element | Density | Melting Range,℃ | Tensile Strength | Yield Strength | Elongation | Hardness (Brinell) |
| SS 347 | 7.96 | 1450 ℃ | 515 | 205 | 40 | 201 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 347 Hex Bars are widely used in aerospace, chemical processing, and power generation for applications requiring high-temperature resistance, corrosion resistance, and strength. They outperform other grades due to their niobium stabilization, preventing carbide precipitation and ensuring durability.
SS 347 Hex Bars typically exhibit a tensile strength of 515-750 MPa, a yield strength of 205 MPa, and an elongation of 40% minimum. These properties ensure high durability, flexibility, and performance in demanding applications.
SS 347 Hex Bars commonly comply with standards like ASTM A276, ASTM A479, ASME SA479, and AMS 5646. These certifications ensure quality, dimensional accuracy, and performance for high-temperature and corrosion-resistant applications across industries, meeting stringent safety and reliability requirements.
The unique qualities of the Stainless Steel 347 Hex Bar and Rod make it indispensable for a range of challenging applications. You’ll commonly find it forming critical components in the aerospace and chemical processing industries, where it’s used for everything from valve stems and pump shafts to fasteners and structural parts in high-temperature equipment. Its hexagonal shape is particularly favored for machining custom parts and creating secure fittings, proving its worth in fabrication shops and industrial plants that demand materials capable of performing reliably under pressure and heat.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
