Welcome to Nimish Metal, your trusted manufacturing partner in the heart of Safat, Kuwait. We take pride in supplying industry-leading Stainless Steel 317L Hex Bars and Rods, engineered for exceptional performance in the most demanding environments. Our commitment is to provide not just a product, but a reliable solution backed by expert knowledge and a dedication to quality that our clients have depended on for years. When you need durability and corrosion resistance you can count on, look no further than our premium 317L stock.
The strength of our 317L alloy lies in its sophisticated composition, which includes higher levels of molybdenum, chromium, and nickel than standard stainless grades. This specific blend gives the material outstanding resistance to corrosion, particularly from acids and chlorides. In terms of mechanical properties, these hex bars and rods offer excellent tensile strength and good ductility, allowing them to maintain their integrity under high stress and elevated temperatures, making them a fundamentally robust choice for critical components.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 317l | 0.03 max. | 18.0 – 20.0 | 2.00 max. | 11.0 – 14.0 | 0.045 max. | 0.03 max. | 1.00 max. |
| Element | Density | Melting Range,℃ | Tensile Strength | Yield Strength | Elongation | Hardness (Brinell) |
| SS 317l | 8 | 1450 ℃ | 515 | 205 | 40 | 217 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 317L Hex Bars/Rods are commonly used in chemical processing, marine environments, pharmaceuticals, and food processing due to their excellent corrosion resistance and high strength. They are ideal for handling aggressive chemicals, including sulfuric acid, bleaching solutions, and pulp liquor. In construction, they are used for structural components and fittings.
SS 317L Hex Bars/Rods typically range from 6 mm to 100 mm in diameter, with lengths up to 6 meters. Tolerances generally conform to ±0.5 mm for diameter. These dimensions and tolerances ensure precision for machining, making them ideal for applications requiring high strength, corrosion resistance, and tight fit.
The high chromium (18-20%) and molybdenum (3-4%) content in SS 317L enhances its resistance to pitting and crevice corrosion by forming a passive oxide layer that protects against chloride-induced degradation. The low carbon content further reduces the risk of stress corrosion cracking, ensuring durability in harsh chloride environments.
You’ll find our Stainless Steel 317L Hex Bars and Rods are the material of choice across several vital industries. They are indispensable in chemical processing plants for constructing reactors and piping systems, and in the oil and gas sector for components exposed to harsh sour environments. Furthermore, their superior resistance makes them ideal for pollution control equipment, pharmaceutical manufacturing, and even in the construction of large industrial vessels and heat exchangers, where failure is simply not an option.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
