Nestled in the industrial heart of Safat, Kuwait, Nimish Metal has built a reputation as a trusted name for high-quality steel products. We are proud to offer the Stainless Steel 317 Hex Bar and Rod, a premium solution designed for the most demanding environments. If your project faces constant attacks from harsh chemicals or extreme temperatures, this alloy provides the resilience and longevity you need to ensure structural integrity and long-term performance, giving you peace of mind that your work is built to last.
The composition of Stainless Steel 317 includes elevated levels of chromium, nickel, and molybdenum, plus a higher carbon content. This specific blend grants it superior resistance to corrosion, particularly against acidic and chloride-rich conditions. In terms of strength, this alloy exhibits excellent mechanical properties, including high tensile strength and good durability, allowing it to maintain its structural integrity under significant stress and in high-temperature settings where other materials might fail.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 317 | 0.08 max. | 18.0 – 20.0 | 2.00 max. | 11.0 – 14.0 | 0.045 max. | 0.03 max. | 1.00 max. |
| Element | Density | Melting Range,℃ | Tensile Strength | Yield Strength | Elongation | Hardness (Brinell) |
| SS 317 | 8 | 1454 ℃ | 515 | 205 | 40 | 217 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 317 hex bars/rods are commonly used in the industrial and construction sectors for their corrosion resistance and high strength. They are utilized in manufacturing chemical processing equipment, marine environments, heat exchangers, pumps, valves, fasteners, and structural components in corrosive conditions, ensuring durability and reliability.
SS 317 hex bars/rods typically range from 6 mm to 100 mm in size, with tolerances as per ASTM A276 or similar standards. Precise dimensions and tight tolerances ensure consistent strength, machinability, and fitment, making them ideal for high-performance applications in chemical, marine, and structural industries.
SS 317's chemical composition, with high levels of chromium (24-26%) and molybdenum (3-4%), enhances its resistance to pitting and crevice corrosion. The molybdenum content improves resistance to chloride-induced corrosion, while the balanced alloying helps prevent stress corrosion cracking, making it ideal for harsh, chloride-rich environments.
From chemical processing equipment and industrial pipelines to marine fittings and pharmaceutical machinery, the applications for our 317 Hex Bar and Rod are vast. Their robust nature makes them ideal for constructing reactors, heat exchangers, and structural components in highly corrosive environments. This versatility ensures that whether you’re in oil and gas, construction, or specialty manufacturing, you have a reliable material that performs consistently, supporting critical infrastructure and enabling innovation in challenging settings.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
