For those in Safat and beyond seeking exceptional strength and reliability, Nimish Metal stands as your trusted local source for precision materials. We are proud to supply the robust Stainless Steel 15-5 PH Hex Bar and Rod, engineered to meet the rigorous demands of various Kuwaiti industries. This premium precipitation-hardening alloy delivers a remarkable combination of high strength and impressive corrosion resistance, making it an ideal choice for critical components where failure is not an option and longevity is essential.
The composition of 15-5 PH stainless steel is carefully balanced, featuring a chromium-nickel base with added copper. This specific formulation allows it to achieve outstanding mechanical properties through a simple heat treatment. After this process, the material offers high tensile and yield strength that is maintained even at elevated temperatures, coupled with good toughness and resistance to stress corrosion cracking, providing a durable and dependable material solution.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 15-5 PH | 0.07 max | 0.15-0.45 max | 14.0-15.0 max | 2.5-4.5 max | Bal | 1.0 | 3.5-5.5 | 0.04 | 0.03 | 1.0 |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 15-5 PH | 161,000 | 140,000 | 7.6% | C35 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 15-5PH | 1.4545 | S15500 |
| HEXAGONS | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Store Stainless Steel 15-5 PH hex bars and rods in a clean, dry, ventilated area, elevated on racks, with protective covers, separated from other metals, and handled carefully.
Stainless Steel 15-5 PH hex bars excel in wear-resistant applications due to their high strength, toughness, excellent corrosion resistance, and ability to maintain hardness after precipitation-hardening heat treatment.
Common challenges with Stainless Steel 15-5 PH hex bars include susceptibility to stress corrosion cracking in chloride environments, limited ductility in hardened conditions, higher machining difficulty, and potential distortion during heat treatment.
The unique properties of 15-5 PH make it perfectly suited for challenging environments. In Kuwait’s industrial landscape, these hex bars and rods are commonly used for manufacturing shafts, valves, pump components, and fasteners in the oil and gas sector. Their strength also makes them invaluable for aerospace parts, chemical processing equipment, and even within the construction of medical instruments. Essentially, any application requiring a material that can handle high stress while resisting corrosion will benefit from this versatile alloy. Nimish Metal is committed to providing this high-quality material to support your most demanding projects right here in Safat.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
