Nestled in the industrial heart of Safat, Kuwait, Nimish Metal has built a solid reputation as a trusted name in the metals trade. We understand that the foundation of any great project lies in the quality of its materials. That’s why we take pride in supplying premium Aluminium 7075 Bar/Rods, offering professionals like you the reliable foundational components needed to turn ambitious designs into resilient, high-performance realities. We’re not just suppliers; we are partners in building excellence.
Aluminium 7075 is a high-strength alloy primarily composed of zinc as the key alloying element, along with magnesium and a touch of copper. This specific composition grants it an exceptional strength-to-weight ratio, making it remarkably strong while remaining lightweight. It also exhibits good mechanical properties, including significant resistance to fatigue, which allows it to withstand repeated stress. In many ways, it provides strength comparable to certain steels, but with a much lighter footprint.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Weight % | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Each | Total |
| Minimum | 1.20 | 2.10 | 0.18 | 5.10 | ||||||
| Maximum | 0.40 | 0.50 | 2.00 | 0.30 | 2.90 | 0.28 | 6.10 | 0.20 | 0.05 | 0.15 |
| Temper | Tensile | Hardness | ||||
| Ultimate | Yield | Elongation | Brinell | |||
| KSI | MPA | KSI | MPA | % | ||
| T6, T651 | 83 | 572 | 73 | 503 | 11 | 150 |
| T73, T7351 | 73 | 503 | 63 | 434 | 13 | N/A |
| UNS | EN | DIN,WNr | JIS | AFNOR | ISO | BS | GOST |
| A97075 | ENAW-AlZn5.5MgCu EN AW-7075 | 3.4365 AlZnMgCu1.5 | 7075 | 7075 A-Z5GU | AlZn6MgCu | 7075 L95 L96 | V95 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 7075 bar is commonly used for structural applications due to its high strength, excellent corrosion resistance, and lightweight properties, making it suitable for aerospace, automotive, and military structural components.
Aluminium 7075 rods are sized based on their diameter and length. Diameters typically range from 1/8" to 12", and lengths vary from 3' to 20', depending on specific customer requirements.
To maintain Aluminium 7075 bar, regularly clean it with mild soap and water to remove dirt. Avoid harsh chemicals, and store it in a dry, cool environment to prevent corrosion and damage.
The superior strength of Aluminium 7075 Bar/Rods makes them the go-to choice for demanding applications where failure is not an option. You’ll often find them in the aerospace industry for aircraft components, in high-performance racing vehicles, and in the intricate parts of military equipment. Beyond that, they are essential for manufacturing heavy-duty machinery, sturdy tooling frames, and even high-end sporting goods. Essentially, any project that requires a material that is both incredibly strong and surprisingly lightweight can benefit from the unique properties of 7075 aluminium.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
