Welcome to Nimish Metal, your trusted partner in Safat, Kuwait, for high-quality aluminium solutions. We take pride in supplying robust and reliable Aluminium 5052 Bar/Rods, designed to meet the demanding standards of various industries. Known for its exceptional versatility, this grade is a top choice for projects requiring a perfect balance of strength, workability, and resistance to the elements. We are committed to providing materials that form the strong, dependable backbone of your most important creations.
The Aluminium 5052 alloy is primarily composed of magnesium and chromium, which gives it a distinctive edge. This specific blend results in outstanding resistance to corrosion, especially in marine environments, making it far superior to many other aluminium grades. It boasts excellent fatigue strength and can be easily machined, welded, and formed into complex shapes without losing its integrity. This combination of properties makes it a remarkably durable and adaptable material for a wide range of fabrication needs.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Mg | Mn | Si | Cu | Fe | Cr | Zn | Ti | Cu | Other (Each) | Others (Total) | Al |
| 2.60 – 3.60 | 0.0 – 0.50 | 0.0 – 0.40 | 0.0 – 0.40 | 0.0 – 0.30 | 0.0 – 0.20 | 0.0 – 0.15 | 0.0 – 0.10 | 0.0 – 0.05 | 0.0 – 0.05 | 0.0 – 0.15 | Balance |
| Proof Stress | Tensile Strength | Elongation at 50 mm | Hardness Brinell |
| 80 Min MPa | 190 – 260MPa | 12 Min % | 52 HB |
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlMg2,5 | AG2,5C | 3.3523 | A95052 | AlMg2,5 | 5052 | AlMg2,5 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 5052 bars can be welded. They offer good weldability using techniques like TIG or MIG welding, making them suitable for a variety of applications in marine and structural industries.
Consider proper handling to prevent surface damage, use appropriate welding techniques, ensure corrosion protection for harsh environments, choose compatible fasteners, and account for temperature fluctuations during installation for optimal performance.
Yes, Aluminium 5052 bars and rods can be used for structural applications due to their excellent corrosion resistance, high strength, and formability, making them suitable for marine, automotive, and industrial uses.
You’ll find Aluminium 5052 Bar/Rods at the heart of countless essential applications. They are indispensable in marine hardware, from boat fittings to gangways, where saltwater resistance is critical. The transportation industry relies on them for truck bodies and aircraft components, while architects and builders use them for decorative trim and architectural facades. They are also perfect for crafting durable fuel tanks, electronic chassis, and a variety of general fabrication projects where a lightweight yet strong material is essential for long-lasting performance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
