Nestled in the industrial heart of Safat, Kuwait, Nimish Metal has built a reputation as a trusted name in the supply of high-performance alloys. We take particular pride in offering Super Duplex Steel Zeron 100 Bars and Rods, a premium-grade material chosen for environments where exceptional strength and corrosion resistance are not just desired, but essential. This commitment provides our clients with durable, long-lasting solutions for their most challenging industrial projects.
Super Duplex Steel Zeron 100 is renowned for its robust composition, which includes chromium, nickel, molybdenum, and tungsten. This specific alloy delivers an outstanding balance of high tensile and impact strength, along with excellent resistance to crevice and pitting corrosion. Essentially, it offers the durability of ferritic steels with the corrosion resistance of austenitic steels, all in one superior package.
| Specifications | ASTM A276, A479, ASTM A182 / ASME SA276, SA479, SA182 |
|---|---|
| Grade | Super Duplex Steel UNS S32760 F55 |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Technique | uns S32760 Cold Drawn, Hot Rolled, Forged Round Bar, Rod, Cold Rolled |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Flat bar size | Thickness: 2 -100mm |
| Billet Size | 1/2″ to 495mm Diameter |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Section | 3.0 to 12.0mm thickness |
| Form | Precision Ground Bar, Flat Bar, Square, Round, Half Round Bar, Rod, Rectangle, Hex (A/F), T-Bar, Channel Bar,Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging, Rings, Hollow, Triangle etc. |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Processing | Bar cutting to 650mm |
| Certificates | EN 10204 / 3.1 |
| Condition | Hardened & tempered, annealed |
| Our uns S32750 Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | Cr | Ni | Mo | C | W | Cu | N | Mn | Si | P | S | Fe |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Zeron 100 | 24.0-26.0 | 6.0-8.0 | 3.0-4.0 | 0.030 Max | 0.5-1.0 | 0.50-1.0 | 0.2-0.3 | 1.00 Max | 1.0 Max | 0.03 Max | 0.01 Max | Balance |
| Grades | Alloy Zeron 100 Tensile Strength, ksi | .2% Yield Strength, ksi | % Elongation in 50mm | Hardness Max. |
|---|---|---|---|---|
| Zeron 100 | 109 | 80 | 25 | 28 HRC |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Zeron 100 | 1.4501 | S32760 |
Yes, Super Duplex Steel Zeron 100 bars can be welded. However, proper welding procedures and pre-heat treatments are essential to avoid issues like cracking and maintain its high strength and corrosion resistance.
Super Duplex Steel Zeron 100 rods are highly resistant to galvanic corrosion due to their exceptional corrosion resistance properties. However, if exposed to more active metals in a corrosive environment, some risk of galvanic corrosion may still exist.
Super Duplex Steel Zeron 100 rods are available in a range of diameters, typically from 10 mm to 300 mm, and can be customized based on specific requirements. They are commonly offered in finishes like hot-rolled, cold-rolled, and bright polished.
You’ll find Zeron 100 Bars and Rods playing a critical role in demanding sectors where failure is not an option. They are commonly specified for components in offshore oil and gas platforms, chemical processing plants, and demanding marine applications. From pump shafts and valve stems to intricate parts in desalination units, this material provides the resilience needed to withstand aggressive chemicals and high-pressure environments, ensuring both safety and operational longevity.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
