Located in the industrial heart of Safat, Kuwait, Nimish Metal has built a strong reputation as a trusted manufacturer and supplier of high-performance materials. We take pride in offering a specialized product line that meets the most demanding industrial needs, including the exceptional Super Duplex Steel Ferralium 255 Bars and Rods. This grade is specifically chosen for its outstanding resistance to corrosion and impressive strength, making it a go-to solution for engineers and fabricators working in some of the toughest environments, right here in Kuwait and across the region.
The strength of Ferralium 255 lies in its sophisticated composition, which blends high levels of chromium, nickel, and molybdenum with a unique addition of copper. This specific formula results in a material that boasts a remarkable combination of high tensile and yield strength, along with excellent toughness. Essentially, it gives you the superior corrosion resistance typical of super duplex steels, but with the added benefit of enhanced mechanical performance, allowing it to handle significant stress and pressure without compromising its integrity.
| Grade | Ferralium 255 |
|---|---|
| Specification | Super Duplex Steel Ferralium 255 Round Bar |
| Square bar size | 4 to 100mm |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Section | 3.0 to 12.0mm thickness |
| Round bar size | Diameter: 3-~800mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Billet Size | 1/2″ to 495mm Diameter | Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Technique | Ferralium 255 Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Form | Ferralium 2507 Round Bar, Rod, T-Bar, Super Duplex Steel Channel Bar, Precision Ground Bar, Super Duplex Steel Flat Bar, Super Duplex Steel Square Bar, Super Duplex Steel Blocks, Super Duplex Steel Round Rod, Super Duplex Steel Rings, Super Duplex Steel Hollow, Super Duplex Steel Triangle, Rectangle, Hex (A/F), Super Duplex Steel Threaded, Ferralium 2507 Half Round Bar, Profiles, Super Duplex Steel Billet, Super Duplex Steel Ingot, I/H Bar, Forging etc. |
| Mo | Cu | Cr | Ni | N | Si | Mn | W | P | S | C | Fe |
| 3.5 | 1.75 | 26 | 6.3 | 0.23 | 0.15 | 0.5 | 1 max | 0.025 max | 0.025 max | Balance | 0.005 max |
| Yield Strength (0.2%Offset) | MPa – 570-600 |
| Tensile Strength | MPa – 790 |
| Elongation | 25 % |
| STANDARD | UNS | DIN |
|---|---|---|
| Ferralium 2507 round bar | S32550 | 1.4507 |
Yes, Super Duplex Steel Ferralium 255 Bars can be welded using suitable techniques like TIG, MIG, or SMAW, ensuring precise heat input control to prevent phase imbalance. Pre-heating and post-weld heat treatments may be required for optimal weld integrity.
Super Duplex Steel Ferralium 255 Rods are highly resistant to galvanic corrosion due to their excellent corrosion resistance properties. However, they may still experience some susceptibility in highly corrosive environments when coupled with more anodic materials.
Super Duplex Steel Ferralium 255 rods are available in a wide range of sizes, typically from 3mm to 500mm in diameter. They are offered in finishes such as hot-rolled, cold-drawn, and polished for various applications.
Because of this robust profile, Ferralium 255 Bars and Rods are indispensable in sectors where failure is not an option. You will find them hard at work in the oil and gas industry, within chemical processing plants, and in demanding marine and offshore applications. They are commonly used for crafting pumps, valves, shafts, and fasteners that must withstand highly corrosive chemicals, seawater, and extreme pressures. Choosing this material means investing in longevity and reliability for your most critical components, reducing downtime and maintenance costs over the long term.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
