Nestled in the industrial heart of Safat, Kuwait, Nimish Metal has built a solid reputation as a trusted source for high-grade metals. We take particular pride in our extensive inventory of Stainless Steel 420 Bars and Rods, known for their excellent durability and strength. We are committed to supplying our clients with materials that meet the most rigorous standards, ensuring your projects are built on a foundation of reliability and superior performance, piece by piece.
Stainless Steel 420 is a martensitic grade that combines chromium enrichment with a higher carbon content than the 410 grade. This composition allows it to achieve a wide range of mechanical properties. It can be heat-treated to develop a good combination of high strength and hardness, making it a tough and resilient material suited for demanding environments where resistance to wear is a critical factor.
| Specification | ASTM A276/ A479, ASME SA276/SA479 |
|---|---|
| Grade | Stainless Steel 420 (UNS S42000) |
| Flat bar size | 1/2” to 10” in thickness range of 2mm to 150mm |
| Square bar size | 18mm – 47mm (11/16″ to 1-3/4″) |
| Round bar size | Outside Diameter in the range of 4mm to 500mm |
| Hex Bar size | 18mm – 57mm (11/16″ to 2-3/4″) |
| Bright Bar | Outside Diameter in the range of 4mm to 100mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Rectangular bar Size | 33 x 30mm to 295 x 1066mm |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Condition | Hardened & tempered, annealed |
| Technique | 420 Stainless Steel Cold Drawn, Hot Rolled, Forged Round Bar, Rod, Cold Rolled |
| Processing | Bar cutting to 650mm |
| Section | 3.0 to 12.0mm thickness |
| Form | Precision Ground Bar, Flat Bar, Square, Round, Half Round Bar, Rod, Rectangle, Hex (A/F), T-Bar, Channel Bar,Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging, Rings, Hollow, Triangle etc. |
| Our 420 Stainless Steel Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | C | Mn | Si | P | S | Cr | |
| 420 | min. | – | – | – | – | – | 12.0 |
| max. | 0.15 | 1.0 | 1.00 | 0.04 | 0.03 | 14.0 | |
| Grade | Tensile Strength (ksi) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (ksi) min | Hardness |
| 420 | 95,000 | 25 | 50,000 | 175 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 420 | 1.4021 | S42000 | SUS 420 J1 | 420S29 | – | – | FeMi35Cr20Cu4Mo2 |
Stainless Steel 420 Bars and Rods are known for their excellent hardness, corrosion resistance, and wear resistance. They are a high-carbon steel that can be heat-treated for maximum hardness and are ideal for applications that require strength and durability, such as cutlery, surgical instruments, and valve parts.
Stainless Steel 420 has higher carbon content compared to other grades like 304 or 316, which allows it to be hardened through heat treatment. This makes it particularly suitable for applications that demand high strength, hardness, and wear resistance, although it may not offer the same corrosion resistance as other austenitic grades.
The inherent hardness of Stainless Steel 420 makes these bars and rods perfect for applications where wear resistance is crucial. You will often find them used in the manufacturing of precision parts like bearings, gauges, and pump components. They are also widely used in the aerospace and automotive industries for everything from surgical tools to fastener systems, proving indispensable wherever a combination of moderate corrosion resistance and significant strength is required.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
