Welcome to Nimish Metal, your trusted partner in Safat, Kuwait, for premium stainless steel solutions. We take pride in specializing in the supply and manufacturing of high-quality Stainless Steel 304H Bars and Rods, catering to the precise demands of various industries. Our commitment is to provide materials that not only meet but exceed expectations, ensuring reliability and durability for your most critical projects. With a focus on excellence and customer satisfaction, we are your go-to source for robust and dependable stainless steel products.
Stainless Steel 304H is a high-carbon version of the classic 304 grade, which gives it enhanced strength at elevated temperatures. Its composition, primarily chromium and nickel, provides excellent resistance to corrosion and oxidation. This specific grade is carefully crafted to offer superior mechanical properties, including high tensile strength and excellent creep resistance. These characteristics make it exceptionally well-suited for applications where the material will face sustained high heat, ensuring long-term performance and structural integrity under demanding conditions.
| Grade | Stainless Steel 304H (UNS S30409) |
|---|---|
| Specification | ASTM A276, ASTM A479 |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Hollow Bar | 32 OD x 16 ID to 250 OD x 200 ID |
| Square bar size | 4 to 100mm |
| Section | 3.0 to 12.0mm thickness |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Billet Size | 1/2″ to 495mm Diameter |
| Channel Bar | 80 x 40 to 150 x 75 mm section; 5 to 6 mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Angle bar size | 3*20*2~12*100*100 mm |
| Form | Rings, Profiles, Hollow, Flat Bar, Square, Round, Rectangle, Triangle, Rod, Half Round Bar, T-Bar, Hex (A/F), Precision Ground Bar, Channel Bar, Blocks, Round Rod, Threaded, Billet, Ingot, I/H Bar, Forging etc. |
| Technique | Cold Drawn, Rod, Hot Rolled, Cold Rolled, Forged Round Bar |
| Condition | annealed, Hardened & tempered |
| Surface | Cold Drawn, Polished, Bright, Hot Rolled Pickled, Sand Blasting Finished,Hairline |
| Element | SS 304H |
| C | 0.10 max |
| Ni | 8.0 – 10.5 |
| P | 0.045 max. |
| Mn | 2.00 max |
| Si | 0.75 max |
| S | 0.03 max. |
| Cr | 18.0 – 20.0 |
| Element | SS 304H |
| Melting Point | 1400 ℃ |
| Density | 8 |
| Hardness (Brinell) | 201 |
| Yield Strength (0.2%Offset) | 205 |
| Tensile Strength | 515 |
| Elongation | 40 |
|
Type |
SIZES (Inches) |
ISO Tolerance |
SIZES (mm) |
|---|---|---|---|
|
Peeled and Polished |
1.50″ to 6.00″ |
h11-DIN 1013 |
40.00 to 150.00 |
|
Cold Drawn and Ground |
5/6″ to 2.50″ |
h9-h8-h11-h10 |
10.00 to 75.00 |
|
Cold Drawn and Polish |
1/8″ to 3.00″ |
h9-h8-h11-h10 |
3.00 to 75.00 |
|
Peeled and Ground |
3/4″ to 2.00″ |
h10-h9-h11 |
20.00 to 50.00 |
| STANDARD | UNS | WERKSTOFF NR. |
| SS 304H | S30409 | 1.4301 |
Stainless Steel 304H has a higher carbon content (0.04–0.10%), which enhances its strength and heat resistance, making it suitable for high-temperature applications compared to 304 and 304L.
Industries such as petrochemical, power generation, chemical processing, and construction use Stainless Steel 304H for applications like heat exchangers, boilers, pressure vessels, and structural components.
Yes, Stainless Steel 304H is designed for excellent performance in high-temperature environments, maintaining strength and corrosion resistance in conditions up to 870°C (1600°F).
The unique high-temperature strength of 304H Bars and Rods makes them ideal for demanding applications. You will commonly find them in components for boilers, pressure vessels, and heat exchangers within power generation and petrochemical plants. They are also extensively used in constructing industrial ovens, furnace parts, and high-temperature piping systems. For any project where components must retain their strength and resist scaling while exposed to persistent heat, 304H provides a reliable and proven solution, ensuring safety and efficiency in critical operations.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
