Welcome to Nimish Metal, your trusted partner in Safat, Kuwait for precision-engineered stainless steel solutions. We specialize in supplying high-quality 316L stainless steel forgings, crafted to meet the demanding standards of various industries. Our commitment lies in providing components that combine exceptional durability with superior corrosion resistance, ensuring your projects are built on a foundation of reliability and long-lasting performance. We understand the critical nature of your applications and are dedicated to delivering forging excellence that you can count on.
The 316L grade is defined by its low-carbon composition, enhanced with molybdenum, which gives it remarkable resistance to corrosive environments, including those containing chlorides. This alloy maintains excellent toughness and strength across a wide temperature range. Its mechanical properties are further refined through the forging process, resulting in a uniform microstructure that offers improved structural integrity and fatigue strength over standard cast or machined parts, making it a robust choice for critical components.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Yes, Stainless Steel 316L can be forged into custom shapes, offering flexibility for various applications. Its excellent machinability allows precise fabrication.
Stainless Steel 316L Forgings require minimal maintenance, primarily periodic cleaning to prevent corrosion buildup. Regular inspections ensure long-term performance and durability.
Stainless Steel 316L Forgings may have limited strength at very high temperatures and can be more expensive than other grades. It may also be susceptible to localized corrosion in certain environments.
The versatility of 316L forgings makes them indispensable across many sectors. They are fundamental in the chemical processing and oil & gas industries for valves, pumps, and pipeline fittings that handle aggressive media. In marine environments, they are used for shipbuilding components and offshore rig hardware. Furthermore, their hygienic qualities and durability make them ideal for pharmaceutical and food processing equipment. Essentially, wherever severe corrosion and high strength are concerns, 316L forgings from Nimish Metal provide a dependable and long-term solution.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
