Nestled in the industrial hub of Safat, Kuwait, Nimish Metal has built a solid reputation as a trusted manufacturer and supplier, particularly when it comes to precision components. We understand that the integrity of your project hinges on the quality of its parts. That’s why we take pride in producing superior Stainless Steel 304L Forgings, a material chosen for its reliability and resilience. We are dedicated to providing solutions that empower industries across the region to build with confidence and lasting strength.
The strength of 304L begins with its composition, which includes a low carbon content alongside a powerful blend of chromium and nickel. This specific formula results in exceptional mechanical properties, including high tensile strength and impressive impact resistance, even in demanding environments. Most importantly, this grade is known for its improved resistance to corrosion and excellent formability after the forging process. These characteristics ensure the final product is not only strong but also highly durable and versatile.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 304L | 1.4306 / 1.4307 | S30403 | SUS 304L | 3304S11 | 03Х18Н11 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 |
Post-forging operations for Stainless Steel 304L include heat treatment, machining, surface finishing, and testing to ensure optimal strength, dimension accuracy, and corrosion resistance.
To determine if Stainless Steel 304L forgings meet your needs, review material certifications, perform quality checks, and ensure they meet required mechanical properties and dimensional standards.
After Stainless Steel 304L forgings, slow cooling in air or controlled environments is recommended to prevent cracking and ensure uniform grain structure and mechanical properties.
Our Stainless Steel 304L Forgings are the silent heroes in many critical applications you might see every day. They are fundamental in constructing robust chemical processing equipment, reliable food and beverage machinery, and heavy-duty marine hardware. You’ll also find them forming essential parts of pumps, valves, and compressor systems where failure is simply not an option. Essentially, whenever a project demands a component that can handle stress, heat, and corrosive elements, our 304L forgings provide the dependable backbone needed for long-term success.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
