In the heart of Kuwait’s industrial hub of Safat, Nimish Metal has built a reputation for precision and reliability, specializing in high-performance metal components. Our expertise shines in the production of Stainless Steel 316 forgings, where we combine skilled craftsmanship with stringent quality control. We understand that our clients need components that can withstand demanding environments, which is why we are committed to delivering forgings that offer exceptional strength and corrosion resistance, ensuring the longevity and integrity of the most critical applications across various industries.
The standout qualities of Stainless Steel 316 stem from its carefully balanced composition, which includes chromium, nickel, and a crucial addition of molybdenum. This alloying blend is what gives the material its superior resistance to pitting and corrosion, especially in challenging chloride-rich settings. When this alloy is forged, the process further enhances its mechanical profile, resulting in a product with excellent tensile strength, impressive yield strength, and good ductility. This combination means components that are not only tough and durable but also capable of performing reliably under high-stress conditions.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
Yes, Stainless Steel 316 forgings can be shaped into custom forms using precision forging techniques, allowing for a wide range of applications in various industries, including marine and chemical sectors.
The ideal temperature range for forging Stainless Steel 316 is between 2100°F to 2300°F (1149°C to 1260°C), ensuring optimal ductility and minimizing the risk of cracking.
The forging process for Stainless Steel 316 typically takes from a few minutes to several hours, depending on the part's complexity, size, and required finishing.
The versatility of Stainless Steel 316 forgings makes them indispensable in sectors where failure is not an option. You will find these robust components at the core of oil and gas processing equipment, within the demanding environments of chemical and petrochemical plants, and in marine applications where saltwater is a constant challenge. They are equally critical in pharmaceutical manufacturing for their hygienic properties and in food processing for their ease of cleaning and resistance to acidic ingredients. Essentially, wherever superior corrosion resistance and structural integrity are paramount, these forgings provide a trusted solution.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
