For those in Kuwait’s demanding industrial sector, finding a reliable source for high-performance alloys is crucial. That’s where Nimish Metal in Safat comes in. As a trusted manufacturer and supplier, we specialize in providing top-grade Inconel 792 bars and rods. We understand that your projects require materials that can withstand extreme conditions, and we are committed to delivering the quality and consistency needed for critical applications right here in Kuwait.
The strength of Inconel 792 lies in its specialized composition, primarily nickel-chromium, enhanced with significant aluminum and titanium for superior age-hardening. This blend results in bars and rods with exceptional mechanical properties, including remarkable tensile strength and outstanding resistance to creep and fatigue. Even when exposed to intense heat, these materials maintain their structural integrity, offering a reliable solution for high-stress environments.
| Specifications | ASTM B116 / ASTM SB116 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | 5 mm to 500 mm |
| Diameter | 0.1 mm to 100 mm |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Length | 100 mm To 3000 mm Long & Above |
| Form | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
| Element | Composition (%) |
| Nickel (Ni) | 60.0 – 65.0 |
| Chromium (Cr) | 12.0 – 14.0 |
| Cobalt (Co) | 9.0 – 10.0 |
| Aluminum (Al) | 3.0 – 4.5 |
| Titanium (Ti) | 3.5 – 4.5 |
| Molybdenum (Mo) | 1.5 – 2.5 |
| Tantalum (Ta) | 0.50 – 1.50 |
| Zirconium (Zr) | 0.02 – 0.15 |
| Boron (B) | 0.010 – 0.020 |
| Carbon (C) | 0.12 – 0.20 |
| Silicon (Si) | ≤ 0.50 |
| Manganese (Mn) | ≤ 0.50 |
| Iron (Fe) | ≤ 3.0 |
| Property | Value |
| Tensile Strength | 1000 – 1400 MPa |
| Yield Strength (0.2%) | 800 – 1100 MPa |
| Elongation | 5 – 15% |
| Hardness | 350 – 450 HB |
| Impact Strength | Good at elevated temperatures |
| Property | Value |
| Density | 8.25 g/cm³ |
| Melting Range | 1260 – 1340°C |
| Thermal Conductivity | 11.2 W/m·K at 20°C |
| Specific Heat Capacity | 0.410 J/g·K at 20°C |
| Electrical Resistivity | 1.22 μΩ·m at 20°C |
| Coefficient of Thermal Expansion | 13.3 x 10⁻⁶ /°C (20-1000°C) |
Yes, Inconel 792 bars and rods are designed for high-temperature applications, providing excellent strength, oxidation resistance, and thermal stability, making them ideal for extreme heat environments.
Yes, Inconel 792 bars and rods are recyclable. Their high nickel and chromium content allows them to be efficiently reused in various industries, reducing waste and promoting sustainability.
Inconel 792 bars and rods generally do not require additional corrosion protection coatings due to their inherent resistance to oxidation and corrosion, especially in high-temperature and harsh environments.
This unique combination of properties makes Inconel 792 ideal for the most challenging tasks. You’ll often find these bars and rods at the heart of gas turbine engines, particularly in turbine blades and discs that face scorching temperatures. They are also essential in aerospace components, industrial furnace parts, and anywhere that demands long-term reliability under a combination of high stress and severe thermal cycling. Essentially, they are the backbone of equipment that operates at the very edge of material capability.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
