Nestled in the industrial heart of Safat, Kuwait, Nimish Metal has built a reputation for supplying high-quality, precision-engineered materials. We are proud specialists in Titanium Grade 11 Forgings, providing robust and reliable components that meet the most demanding industrial standards. Our commitment lies in delivering more than just a product; we offer solutions built on integrity and a deep understanding of our clients’ unique challenges, ensuring your projects benefit from superior strength and exceptional corrosion resistance right here in Kuwait.
Titanium Grade 11 is a uniquely resilient alloy, distinguished by its addition of a small amount of palladium. This subtle enhancement significantly boosts its resistance to corrosion, particularly in challenging environments like saltwater and acidic solutions. Mechanically, it offers an excellent balance, providing good ductility and formability alongside a moderate strength level. This combination makes it easier to fabricate into complex shapes while maintaining the legendary toughness and lightweight nature inherent to titanium alloys.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 11 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | 12 – .25 |
| Grade | Tensile Strength min | Yield Strength (0.2 % Offset) | Elongation | Reduction of Area | ||
| ksi | Mpa | ksi | Mpa | min % | min % | |
| 11 | 35 | 240 | 25 | 170 | 24 | 30 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 11 | 3.7225 | R52550 |
Yes, Titanium Gr 11 forgings are highly corrosion-resistant, especially to oxidizing environments and seawater. This makes them ideal for applications in industries like aerospace, marine, and chemical processing, ensuring long-lasting durability.
Titanium Gr 11 forgings are commonly used in industries such as aerospace, marine, chemical processing, medical, and power generation. Their strength, corrosion resistance, and high-performance capabilities make them ideal for demanding applications.
Yes, Titanium Gr 11 forgings can be customized for specific applications, offering tailored sizes, shapes, and properties to meet unique industry requirements, ensuring optimal performance and reliability in demanding environments.
The exceptional corrosion resistance of our Titanium Grade 11 Forgings makes them indispensable in critical applications. They are the material of choice for chemical processing equipment, where they handle aggressive acids and chlorides. In marine and offshore industries, these forgings are vital for components like heat exchangers, pump bodies, and valves constantly exposed to seawater. Furthermore, their biocompatibility and reliability make them equally suitable for pharmaceutical plant machinery and even specific surgical implants, wherever failure is not an option.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
