Nestled in the industrial heart of Safat, Kuwait, Nimish Metal has built a strong reputation for delivering exceptional quality and reliable service. We take pride in our expertise with high-performance alloys, particularly our specialized range of Super Duplex Steel S32760 Forgings. Engineered to endure the most challenging environments, these forgings are a cornerstone of our offering, providing clients across the region with components that offer outstanding strength and longevity for their most critical applications.
The exceptional resilience of Super Duplex Steel S32760 stems from its carefully balanced composition, which includes high levels of chromium, nickel, molybdenum, and nitrogen. This unique blend gives the material a robust duplex microstructure, resulting in forgings that possess remarkable yield strength and impressive tensile strength. They also offer excellent toughness and outstanding resistance to pitting and crevice corrosion, far surpassing the capabilities of standard stainless steels.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32760 | 7.8 | 0.281 | 1350 | 2460 |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex S32760 | 1.4501 | S32760 |
Yes, Super Duplex Steel S32760 forgings are highly suitable for offshore and marine applications due to their excellent corrosion resistance, high strength, and resistance to pitting, crevice corrosion, and chloride stress cracking.
Welding processes compatible with Super Duplex Steel S32760 forgings include Tungsten Inert Gas (TIG), Metal Inert Gas (MIG), and Shielded Metal Arc Welding (SMAW), using matching filler materials to maintain corrosion resistance.
Super Duplex Steel S32760 forgings are governed by ASTM A182, ASTM A240, ASME SA-182, and EN 10088-3 standards, ensuring quality, corrosion resistance, and mechanical properties for demanding industrial applications.
These robust mechanical properties make Super Duplex S32760 Forgings indispensable in sectors where failure is not an option. They are widely used in the demanding environments of offshore oil and gas platforms, chemical processing plants, and desalination units, where they withstand highly corrosive seawater and aggressive chemicals. You’ll also find these reliable components in marine engineering, pollution control systems, and pharmaceutical equipment, proving their versatility and unmatched durability in high-stress, corrosive applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
