Based in the industrial heart of Safat, Kuwait, Nimish Metal has built a solid reputation for supplying high-integrity materials, with our Inconel 625 forgings standing as a prime example of our commitment. We understand that in critical industries, component reliability is non-negotiable. That’s why we focus on providing forgings that are not just products, but foundational pieces for enduring projects. Our process ensures that each Inconel 625 forging delivers exceptional strength and resistance, giving our clients in Kuwait and beyond the confidence that their most demanding applications are supported by locally-available, world-class materials.
The strength of Inconel 625 comes from its special composition, primarily nickel and chromium, fortified with niobium and molybdenum. This alloy works in harmony to create a material that is incredibly tough and versatile. It maintains remarkable tensile and yield strength even when faced with extreme temperatures, from sub-zero chill to intense heat up to 1800°F. Furthermore, it offers outstanding fatigue strength and is resistant to a wide range of corrosive elements, including oxidation and pitting, making it a consistently reliable choice under severe stress.
Specifications ASTM B564 / ASME SB564, AMS 5666
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| Grade | C | Mn | Si | S | Al | Ti | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | 0.40 max | 0.40 max | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa -930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Alloy 625 | N06625 | 2.4856 | NC22DNB4M | NiCr22Mo9Nb | NCF 625 | NA 21 | ХН75МБТЮ | ЭИ602 |
Temperature control during forging of Inconel 625 ensures optimal material properties, preventing brittleness and maintaining its strength and ductility. Proper temperature management also enhances uniformity, reducing defects and improving overall quality.
Inconel 625 Forgings are expensive due to the high cost of raw materials and complex manufacturing processes. Additionally, their workability can be challenging at certain temperatures, requiring specialized equipment and techniques.
To determine if Inconel 625 Forgings meet your needs, compare their material properties with your application requirements and consult with suppliers for tailored solutions.
You’ll find Inconel 625 forgings hard at work in the most challenging environments imaginable. They are essential in aerospace for engine components and exhaust systems, and in marine engineering for propeller blades and submarine parts due to their superb saltwater resistance. The oil and gas industry relies on them for downhole wellhead equipment, while chemical processing plants use them in reactors and piping systems that handle aggressive chemicals. Essentially, wherever conditions involve high stress, corrosive media, or elevated temperatures, these forgings provide the necessary durability and long service life.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
