Nestled in the industrial hub of Safat, Kuwait, Nimish Metal stands as a reliable name for high-grade industrial components. We take particular pride in our expertise with Duplex Steel S32205 Forgings, engineered for environments where failure is not an option. Our process emphasizes meticulous quality control from raw material selection to the final product, ensuring every forging delivers the resilience and performance expected from a leading supplier. When you partner with Nimish Metal, you are choosing a trusted source for critical-path components built to withstand the most aggressive conditions.
The composition of Duplex Steel S32205 is a careful balance, primarily blending chromium, nickel, molybdenum, and nitrogen. This specific recipe gives the forgings an exceptional strength-to-weight ratio and mechanical properties that far surpass many standard stainless steels. They boast impressive yield strength and hardness, while maintaining good ductility for tough applications. Perhaps their most valued characteristic is the outstanding resistance to stress corrosion cracking, making them incredibly durable under pressure and in challenging environments.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32205 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
| STANDARD | WERKSTOFF NR. | UNS | SAF |
| Duplex Steel S32205 | 1.4462 | S32205 | 2205 |
Duplex Steel S32205 forgings are available in various sizes, including round, square, and custom shapes. They can range from small to large diameters and lengths, depending on application requirements.
Yes, S32205 Duplex Steel forgings are highly resistant to corrosion, particularly in chloride-rich environments. They offer excellent resistance to pitting, crevice, and stress corrosion cracking, making them ideal for harsh conditions.
The maximum operating temperature for Duplex Steel S32205 forgings is typically around 300°C (572°F). Beyond this, the material's strength and corrosion resistance may degrade due to sensitization and phase changes.
These forgings are indispensable in sectors where both strength and corrosion resistance are paramount. You will find them forming critical parts like pumps, valves, and shafts in offshore oil and gas extraction, as well as in demanding chemical processing plants. They excel in handling aggressive fluids and high-pressure systems. Furthermore, industries such as marine engineering and power generation rely on these components for their longevity and reliability, ensuring safe and efficient operations in some of the toughest industrial settings imaginable.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
